ข้อมูลจำเพาะ

Printer Type:

Printer Type:Print, Scan, Copy, Fax with ADF

Printing Technology:

Print Method:PrecisionCore^TM Printhead
Minimum Ink Droplet Volume:3.8 pl
Print Direction:Bi-directional printing
Nozzle Configuration:800 x 1 nozzles Black, 256 x 1 nozzles per colour (Cyan, Magenta, Yellow)
Maximum Resolution:4800 x 2400 dpi
Automatic 2-sided Printing:Yes (up to A3)

Print Speed:

Photo Default – 10 x 15 cm / 4 x 6 ” ^*1:Approx. 43 sec per photo (Border) / 52 sec per photo (Borderless)^*2
Draft, A4 (Black / Colour):Up to 32.0 ppm / 22.0 ppm ^*2
ISO 24734, A4 Simplex (Black / Colour):Up to 25.0 ipm / 12.0 ipm ^*2
ISO 24734, A4 Duplex (Black / Colour):Up to 16.0 ipm / 9.0 ipm ^*2
ISO 24734, A3 Simplex (Black / Colour):Up to 13.5 ipm / 6.0 ipm ^*2
ISO 24734, A3 Duplex (Black / Colour):Up to 10.0 ipm / 5.0 ipm ^*2

Copy Function:

Reduction / Enlargement:25 – 400%
Maximum Copy Size:A3
Copy Resolution:600 x 600 dpi
Max Copies:999 copies

Copying:

ISO 29183, A4 Simplex Flatbed (Black / Colour):Up to 23.0 ipm / 10.0 ipm
ISO 24735, A4 Simplex ADF (Black / Colour):Up to 22.5 ipm / 10.0 ipm
ISO 24735, A4 Duplex ADF (Black / Colour):Up to 15.5 ipm / 7.5 ipm

Scanning:

Scanner Type:Flatbed colour image scanner
Sensor Type:CIS
Optical Resolution:1200 x 2400 dpi
Maximum Scan Area:297 x 431.8 (mm)
Scanner Bit Depth (Colour):48-bit input, 24-bit output
Scanner Bit Depth (Grayscale):16-bit input, 8-bit output
Scanner Bit Depth (Black & White):16-bit input, 1-bit output

Scan Speed:

Scan Speed (Flatbed / ADF (Simplex | Duplex):200dpi, Black: 5 sec / Up to 26.0 ipm | 11.5 ipm
200dpi, Colour: 10 sec / Up to 9.0 ipm | 6.0 ipm

ADF Specifications:

Support Paper Thickness:64-95 g/m²
Paper Capacity:50 sheets

Fax Function:

Type Of Fax:Walk-up Black-and-white and Colour Fax Capability
Receive Memory / Page Memory:6MB, Page memory
Up to 550 pages
Error Correction Mode:ITU-T T.30
Fax Speed (Data Transfer Rate):Up to 33.6 kbps, Approx. 3 sec/page
Fax Resolution:Up to 200 x 200 dpi
Transmission Paper Size (Flatbed):A5, A4, A3, B5, B4, Half Letter, Letter, Legal, 11 x 17″
Transmission Paper Size (ADF):A5, A4, A3, B5, B4, Half Letter, Letter, Legal, 11 x 17″
Receiving Paper Size:Half Letter, A5, B5, A4, Letter, Legal, B4, 11 x 17”, A3, A3+
Speed Dial / Group Dial:Up to 200 numbers, 199 groups
Fax Features:PC Fax (Transmission/Receive), Automatic Redial, Address book, Broadcast Fax (Mono Only), Transmit Reservation, Polling Reception, Fax Preview, Memory reception, Fax to Email, Fax to Folder, Automatic 2-sided Fax

Paper Handling:

Number of Paper Trays:3 (Front 2, Rear 1)Standard Paper Input Capacity:Cassette 1: 250 sheets for A4 Plain paper (80g/m²)
50 sheets for Premium Glossy Photo Paper
Cassette 2: 250 sheets for A4 Plain paper (80 g/m²)
Rear Slot: 50 sheets for A4 Plain paper (80 g/m²), 20 sheets for Premium Glossy Photo Paper
Output Capacity:125 sheets for A4 Plain paper (80 g/m²), 20 sheets for Premium Glossy Photo Paper
Maximum Paper Size:329 x 6000 mm
Paper Sizes:A3, Super B (13 x 19″), Indian Legal, Letter, A4, 16K (195 x 270mm), 8K (270 x 390mm), Executive (7.25 x 10.5″), B4, B5, A5, B6, A6, 8.5 x 13″, 5 x 7″, 4 x 6″, 8 x 10″, Legal (8.5 x 14″), 16:9 wide, Envelopes: #10, DL, C6, C4
Paper Feed Method:Friction feed
Print Margin:3mm top, left, right, bottom via custom settings in printer driver

Card Slot / USB Host Function:

Type of Direct Printing:USB Memory

Mobile and Cloud Solutions:

Epson Connect Features:Epson iPrint, Epson Email Print, Remote Print Driver, Scan to Cloud
Other Mobile Solutions:Apple AirPrint, Mopria Print Service

Supported OS and Applications:

Supported OS:Windows XP / Vista / 7 / 8 / 8.1 / 10, Windows Server 2003 / 2008 / 2012 / 2016 / 2019
Mac OS X 10.6.8 or later

Noise Level:

PC Printing / Plain Paper Default ^*3:Sound Power (Black / Colour) 6.7 B(A) / 6.2 B(A), Sound Pressure (Black / Colour) 52 dB(A) / 47 dB(A)

Dimensions and Weight:

Dimensions (W x D x H):515 x 500 x 350mm
Weight:20.7kg

Consumables:

Maintenance Box:C12C934591
Pigment Black Ink Bottle:7,500 pages ^*4 – 008 (C13T06G100 / C13T06G199 (Indonesia))
Pigment Cyan Ink Bottle:6000 pages (Composite Yield) ^*4 – 008 (C13T06G200 / C13T06G299 (Indonesia))
Pigment Magenta Ink Bottle:6000 pages (Composite Yield) ^*4 – 008 (C13T06G300 / C13T06G399 (Indonesia))
Pigment Yellow Ink Bottle :6000 pages (Composite Yield) ^*4 – 008 (C13T06G400 / C13T06G499 (Indonesia))

Interface:

USB:USB 2.0
Network:Ethernet, Wi-Fi IEEE 802.11 b/g/n, Wi-Fi Direct
Network Protocol:TCP/IPv4, TCP/IPv6
Network Management Protocols:SNMP, HTTP, DHCP, BOOTP, APIPA, PING, DDNS, mDNS, SNTP, SLP, WSD, LLTD

Power:

Rated Voltage:AC 220 – 240 V
Rated Frequency:50 – 60 Hz
Power Consumption:Operating: 19.0 W
Standby: 9.1 W
Sleep: 0.8 W
Power off: 0.2 W

Printer Software:

Software Support:Epson ScanSmart

Control Panel:

LCD Screen:4.3″ Colour LCD Touch Screen
